Fast DC Prime
Charging Complex
up to 320kW
More than just charging
from 40kW €8,500
to 320kW €33,000
EXW Prices
Powerful complex for mid-duration charging
The charging station is ideal for locations where people spend a short period of time resting, working, or exercising.
These locations include:
Cinema
Gyms
Office
Cafes
Grocery
Malls
Connectors and capacities
We recommend the following charging station equipment standards. However, you can customize the equipment to best suit your application. Just specify which connectors you want to have on board the station when ordering.
AC Input - 255~490V / 640A
DC Output
(Hight voltage) - 1,000V / 320A
(Low voltage) - 500V / 640A
AC Output - 400V / 125A
USA standard
+
+
+
CCS Type 1
1,000V / 320kW / 240kW*
CHAdeMO
1,000V / 80kW
CHAdeMO
1,000V / 80kW
CCS Type 1
1,000V / 320kW / 240kW*
* The indicated capacity for charging one vehicle is 320 kW for CCS Type 1 or 80 kW for CHAdeMO.
When charging two or more vehicles, the power is divided by 240 kW for CCS Type 1 and 80 kW for CHAdeMO.
Europe standard
+
+
+
+
.png)
+
CCS Type 2
CHAdeMO
CHAdeMO
CCS Type 2
Type 2 (Mennekes)
Type 2 socket
E-Bike socket
1,000V / 320kW / 240kW*
1,000V / 80kW
1,000V / 80kW
1,000V / 320kW / 240kW*
400V / 63A / 43kW
400V / 63A / 43kW
230V / 16A / 3.5kW
* The indicated capacity for charging one vehicle is 320 kW for CCS Type 2 or 80 kW for CHAdeMO.
When charging two or more vehicles, the power is divided by 240 kW for CCS Type 2 and 80 kW for CHAdeMO.
Universal standard
+
+
+
+
.png)
+
CCS Type 2
CCS Type 1
1,000V / 320kW / 240kW*
CHAdeMO
GB/T
GB
Type 2 (Mennekes)
Type 1 (J1772)
1,000V / 80kW
1,000V / 120kW / 80kW*
400V / 63A / 43kW
400V / 63A / 43kW
208/240V / 80A / 19kW
* The indicated capacity for charging one vehicle is 320 kW for CCS Type 1 or CCS Type 2, 80 kW for CHAdeMO or 120 kW for GB/T (DC).
When charging two or more vehicles, the power is divided into 240 kW for CCS Type 1 or CCS Type 2 and 80 kW for CHAdeMO or GB/T (DC).
Available configurations
Capacity
from 40 kW to 320 kW
Installation
floor mounted
Capacity
from 40 kW to 160 kW
Installation
wall mounted
TOWER CHARGER
WALL CHARGER
Communication
Information display:
LCD screen 17” in English / Italian / German / French / Spanish / Ukrainian / Polish / Czech / Macedonian / Russian / Any other language according to clients specifications
Methods of connecting the charging station to the billing system are available:
2G, 3G, 4G, LAN, Wi-Fi
OCPP protocol support:
1,6 JSON
Access and activation:
RFID cards (Mifare standard), local list memory - 10000+ cards Mobile application P&C by VIN code / credit card terminal choosed by owner
Support for the following payment methods:
Online terminal, Visa, MasterCard, American Express, Apple Pay, Google Pay
.png)
Size and installation
Mounting:
Wall-mounted
or pedestal (on a concrete base)
Charging station size (H×W×D):
Tower charger:
92.12 x 39.37 x 19.64 inch /
2,340 × 1,000 × 499 mm
Wall charger:
46.14 x 39.37 x 20.66 inch /
1,172 × 1,000 × 525 mm
Length of cables:
From 21.33 ft / 6.5 m
Charging station protection
Enclosure:
Stainless steel
Protective equipment:
The charging station is equipped with a controller with an electronic RCD (30mA, 3 phases)
Enclosure protection class IP54
Mechanical protection class IK10
Operating temperature range:
From ‐35°C to +50°C / -31°F to +122°F
Warranties and manufacturers
Warranty:
24 months
Charging station manufacturer:
Ukraine
Manufacturing components:
European Union, USA, Ukraine, Korea
CE, ISO, EAC and etc. (certification in progress)
The number of cars that can be charged at the same time:
5 cars
Tested with all EV cars and Plug-in Hybrid models
Calculation of the
station average payback
In order to calculate the payback* of a charging station, let's use the next steps:
The cost of the 320kW charging complex is €33,000
Minimum station load 10% of the day. Station charging (~2.5 h/day)
The charging station has a capacity of
320kW
Minimum net profit from sales of 1 kW
€0.2
1. Calculation of the min number of energy sales per day
Minimum operating time of the charging station
2.5h/day
Charging station capacity
320kW
Minimum electricity sales per day
800kWh
2. Calculation of the min profit from energy sales per day
Minimum electricity sales per day
800kWh
Minimum clear profit from sales of 1 kW
€0.2
Minimum profit from energy sales per day
€160
3. Calculating the payback of the station
Price of the charging station
€33,000
Minimum profit from energy sales per day
€160
Estimated payback period of the station
~206 days
According to these calculations, the estimated payback period for the plant is 206 days.
*Individual consumption per charging station may vary depending on geography, traffic corridor, proximity to highly-trafficked areas, daily load profile, etc.
